Ulefone Armor 24 Waterproof Rugged Smartphones 6.78Inch 24GB 256GB Android 13 Mobile Phone 64MP Camera 22000mAh 4G Cellphone NFC

Armor 24 Specifications

647g (phone)

• Built-in LED Light

• 22000mAh Mega Battery

• 6.78" FHD+ 120Hz 1080 x 2460 FHD+

• MediaTek Helio G96

• 24GB RAM =12GB +12GB virtual RAM
  (The virtual RAM can be activated in Settings at your will. )

• 256GB ROM

• 64MP Main Rear Camera

• 64MP Night Vision Camera

• Details: SONY IMX686 CMOS sensor, 0.8μm, 6 piece lens, FOV 79.8°, ƒ/1.89 large aperture

• Details: OV64B CMOS sensor, FOV 79.8°, ƒ/1.79 large aperture

• Running Updated Android 13

• NFC + Google Pay, IR Blaster Support

• 4G/3G/2G(Not compatible with AT&T, Cricket, Sprint,Verizon, Boost Mobile)

• Packing List

• 4G: FDD-LTE: B1/2/3/4/5/7/8/12/17/19/20/28A/28B/66
  TDD-LTE: B34/38/39/40/41
  3G: WCDMA: B1/2/4/5/8
  2G: GSM: B2/3/5/8

• 1x Phone
  1x AC Power Charger( EU Plug)
  1x Data Cable (100cm)
  1x Protective Film (Pre-installed)
  1x SIM Needle
  1x Lanyard
  1x Multi-language User Manual
  1x Multi Function Instruction Card
  1x Warranty Card
  1x Charging Instruction Card
  1x Safety Prompt Card
  1x Acessories Ecosystem Brochure

Armor 24 Specifications

Physical Characteristics

Color

Black

Material

PC

USB

Type-C, USB 2.0

Headphone Jack

3.5mm

Card Slots

3, 1x Nano-SIM + 1x Nano-SIM + 1x microSD

Size & Weight

Product Size

181.2*87*27.5 mm

Product Weight

647g (phone)

Package Size

103.5*197.5*64.5 mm

Product size and weight may vary by configuration, manufacturing process and measurements. All specifications are subject to the actual product.

Ruggedness

Certification

IP68/IP69K/MIL-STD-810H

Working Temperature

-20℃ – 55 ℃ (-4℉ – 131℉)

Display

Screen Size

6.78-inch (*6.78 inches is the diagonal length of the display when the four rounded corners are taken to be pointed corners, the actual viewable area is slightly smaller.)

Screen Resolution

1080 x 2460 FHD+

Aspect Ratio

20.5:9

PPI

396

Color Depth

8bit, 16.7M

Refresh Rate

120Hz

Screen-to-Body Ratio

84%

Multi-touch

10

Processor

CPU Model

MediaTek Helio G96

Main frequency

2.05GHz

CPU Core

8, 2 x Arm Cortex-A55, 6 x Arm Cortex-A76

GPU

Arm Mali-G57 MC2 1.0GHz

RAM & Storage

RAM

24GB RAM=12GB +12GB (The virtual RAM can be activated in Settings at your will. )

ROM

256GB

Max. Expansion Supported

2TB

Rear Camera

Rear Camera Numbers

2

Main Rear Camera

Pixel: 64MP

Details: SONY IMX686 CMOS sensor, 0.8μm, 6 piece lens, FOV 79.8°, ƒ/1.89 large aperture

Night Vision Camera

Pixel: 64MP

Details: OV64B CMOS sensor, FOV 79.8°, ƒ/1.79 large aperture

Flash

1

Video Recording Resolution

2K@30fps, 1080P@30fps, 720P@30fps, 480P@30fps

Special Features

Normal mode, Night Vision Mode, Film Mode, 64MP Mode, Night Mode, Gif, Portrait, Pro Mode, Panorama, Slow Motion, Time Lapse, Intelligent Scanning

Front Camera

Pixel

16MP

Details

S5K3P8 sensor, 1.0μm, 6 piece lens, FOV 76.3°, ƒ/2.2 large aperture

Video Recording Resolution

1080P@30fps, 720P@30fps, 480P@30fps

Special Features

Normal mode, Film, Gif, Portrait

Battery & Charging

Capacity

22000mAh

Watt Hours Per Battery

85.14 Wh

Battery Type

Li-polymer battery

Charging Details

66W, 11V/6A

Standby Time

1300 Hours

Talk Time

100 Hours

Network & Connectivity

Card Type

Nano+Nano+microSD

Cellular

4G/3G/2G(Not compatible with AT&T, Cricket, Sprint,Verizon, Boost Mobile)

4G: FDD-LTE: B1/2/3/4/5/7/8/12/17/19/20/28A/28B/66
TDD-LTE: B34/38/39/40/41

3G: WCDMA: B1/2/4/5/8

2G: GSM: B2/3/5/8

Standby Mode

Dual sim dual standby

VoLTE

Support

WiFi

2.4G/5G, 802.11 a/ac/b/g/n

Bluetooth Version

BT5.2

Navigation

GPS/GLONASS/Beidou/Galileo

Audio

Speaker Numbers

1

Speaker Model

1326 Box

Smart PA

AW88394

Security

Fingerprint ID

Support

Face Unlock

Support

System & Features

Android Version

Android 13

Language

Indonesian, Malay, Catalan, Czech, Danish, German, Estonian, English, Spanish, Filipino, French, Croatian, Italian, Latvian, Lithuanian, Hungarian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Finnish, Swedish, Vietnamese, Greek, Turkish, Bulgarian, Russian, Serb, Ukrainian, Armenian, Hebrew, Urdu, Arabic, Persian, Hindi, Bengali, Thai, Korean, Burmese, Japanese, Simplified Chinese, Traditional Chinese

Blinking Notification Light

Support, red/green/blue light

Battery Status Light

Support

Audio Format Supported

MID/FLAC/MP3/M4A/AAC/AMR/OGG

Video Format Supported

MOV/MKV/3GP/MP4

Image Format Supported

GIF/JPEG/PNG/BMP

Text Format Supported

TXT/HTML

FM Radio

Support,headset-free FM radio

Cell Broadcast

Support

Sensor

Proximity Sensor, Gravity sensor, Light Sensor, Acceleration Sensor,
Geomagnetic sensor, Gyro sensor, Coulomb counter,
Pedometer, Infrared sensor

Special Features

Underwater Camera

Support

Gloves Mode

Support

Digital Toolbox

Height Meter, Compass, Gradienter, Flashlight, Hanging Painting, Magnifier, Alarm bell, Plumb bob, Protractor, Noise Test, Pedometer

OTG Function

Support, max 10W reverse charging

NFC

Support

IR Blaster

Support

Others

Packing List

1x Phone
1x AC Power Charger ( EU Plug)
1x Data Cable (100cm)
1x Protective Film (Pre-installed)
1x SIM Needle
1x Lanyard
1x Multi-language User Manual
1x Multi Function Instruction Card
1x Warranty Card
1x Charging Instruction Card
1x Safety Prompt Card
1x Acessories Ecosystem Brochure

Product Certification

CE, IC, IP68, IP69K, MIL-STD-810H, WEEE, ROHS.TAC, UN38.3,MSDS, IEC62133
