Raedian Home Balance 22kW ev charger MID Solar Powered EV Charging,DLB OCPP16j Wallbox electric car charger 4G AC Wallbox
$1,993.98 – $2,077.08
Description
- Operating Temperature: 45°
- Cable Length: 5M
- IP Rating: IP55
- Voltage: 220V-400V
- Current: 10A-32A
- Material: Metals and plastics
- weight: 6KG
- Charger Type: AC Mode 3
- Power: 7KW-22KW
- Brand Name: jeekvisen
- All Grid & Earthing System: 1 or 3 phase, TT/TN/IT
- Built to Last: Full speed unstop at 45°C
- Weather, impact-proof: IP55,IK10
- Home Balance: dynamically adjust charging
- Display: OLED Display with status indicator and metering informationOLED Display with status indicator and metering information
- Load management: Via App, CT Clamp, MODBUS RTU via RS-485
- Interface: WiFi, BLE, CT Clamp, RS-485,
- Backend protocol: OCPP 1.6 JSON
- User authentication: RFID, App, Plug-n-Charge
- Energy metering: ±1% MID Class B Certified
- Residual current protection: Type A 6mA d.c. per IEC 62955
- Protection: UVP, OVP, OCP, Relay Stuck, Over Temperature
Charge any EV with tether cable & socket in compliance with your local standard.Charge on any earthing system & fully compliant with regional requirements like OPCC.
Seamless integration with your solar and energy storage system, with turn-key solution to optimize your charging schedule, charging cost and clean energy self independent.
Sustainable home electricity and charging through PV and BESS
Home Balance Mode
With connected CT clamps or RAEDIAN Hub Home Energy Gateway, RAEDIAN Wallbox will dynamically balance the home electricity and EV charging, always keep your overall power under control.
Solar Mode
RAEDIAN Wallbox will monitor the surplus power from the Solar PV, and only utilize the surplus power to charge your EV.
Solar Plus Mode
RAEDIAN Wallbox will maximize the utilization of the surplus energy from Solar PV, together with the power from the grid, to charge your EV at your selected amperes.
